I posted some photos of this engine in progress a few months ago & now that it's finished I figured I'd post a couple to show what a Berkeley 492 engine and powertrain looks like. That's the whole shebang, engine, transmission (4 spd + rev), differential, starter, and generator. The starter & generator are a combined "Dynastart" unit and are on the right under the rag in the top picture.
These engines are modular and could theoretically be expanded to more cylinders. The small inset photo shows it from the front and you can probably see that the crankcase is split into multiple segments and the cylinders are all independent. The crankshaft is a built-up unit with roller bearing big ends and ball bearing mains. Each segment is a separate engine. The crank sections would need some work, though.
The "modular engine" idea was patented by (British) Excelsior after being developed for this engine.
Next project is to improve the shop itself a little, then maybe I'll tackle the car itself.
