HEY,i'm on the slow road to building MY ultimate triumph. Here's the build sheet:
-1962 tr4 Original colours:brg exterior,red with white piping seat covers and panels, white dash, white roll bar,white soft top
-roller rockers(harland sharpe)
-alternator conversion
-modern starter
-thin belt conversion with harmonic dampener
-ported head @ 10:1 compression (pump gas 94 chevron)
-dellortos(twin side drafts)
-electronic distributor (lucas lotus part)
-crane msd electronic ignition module with built in rev limiter
-nitrided crank, cam, rocker shaft, oil pump shaft
-carillo rods
-89mm pistons
-aluminum radiator with electric fan
-remote oil cooler with thermostat
-1992 toyota supra 5-spd transmission(dellow automotive australia adaptor)
-tilton brake pedal assembly with balance bar(twin brake masters)
-wilwood dyna-pro 4-pot calipers (dust boots included)
-.81" 11" dia vented brake rotors with aluminum hats(wilwood)
-aluminum rear brake drums
-phantom grip limited slip diff
-racetorations front hubs(aluminum)
-southwick machine rear axles
-revington adjustable anti roll bars 1"front 5/8" rear
-poly and nitralon bushings
-revington upper a-arm relocation mount
-avo front shocks, adjustable
-smithies rear shock upgrade (australia)
-widened original steel wheels with hub caps (get offsets perfect and still have stock appearing wheels with correct number of holes,tr6 wheels have more holes)
-custom made perfectly equal length header.by me
-ceramic coatings on headers, pistons, combustion chamber, exhaust port
-ss thin stem valves
-titanium valve retainers
-schubeck ceramic lifters
-completely stock appearing from the outside, almost (a little develish under the hood)
-custom made seats to look similar to originals (but actually fit with support and cumfort)by me
-lots of other tricks not mentioned.
***if i win the lotto-----electromotive efi and crank trigger ignition.
rob
