TR6 Bolt size/thread count for fuel sender TR4/TR6

tdskip

Yoda
Country flag
Offline
Well so much for the idea that I was diligent on packing and labeling everything.

Anyone know off hand the thread size/count for the thread that are used to secure the fuel sender to the tank by chance?

Moss #323-370 or #28 in the schematic below.



Thanks!


DNK

Great Pumpkin
Country flag
Offline
I have em out in the garage in a bag if you need em!


TR3driver

Great Pumpkin - R.I.P
Offline
Stanpart TR6504, which is 10-32 by 1/2" long.


DNK

Great Pumpkin
Country flag
Offline
10/32's X 3/8s oval head straight tip.
Copper washer?

OP
T

tdskip

Yoda
Country flag
Offline
Man is it ever nice to be putting something back together for a change. The 10/32 worked a treat guys - thanks again!


Gliderman8

Yoda
Gold
Country flag
Online
Yep... I concure... 10/32's is it!


DNK

Great Pumpkin
Country flag
Offline
no, each of them little screws has a fiber washer


TR3driver

Great Pumpkin - R.I.P
Offline
DNK said:
no, each of them little screws has a fiber washer
Only fiber washers on mine are where the bolt/stud for the wire passes through the plate. The bolts that hold the sender to the tank only have internal star lock washers (P/N WN0705) per the SPC.


DNK

Great Pumpkin
Country flag
Offline
all of mine has a small which I thought copper washer. The diagram Tom posted list a fiber washer


TR3driver

Great Pumpkin - R.I.P
Offline
In the immortal words of Emily Litella:


Attachments

  • 21556.jpg
    23.9 KB · Views: 779

TR3driver

Great Pumpkin - R.I.P
Offline
Apparently TR4-6 did have fiber washers, TR2-3 had lock washers.

My bad.
