MGA Fuel gauge question

Coastalman

Jedi Warrior
Silver
Country flag
Offline
My latest project in fixing the little things that are not working on my 1962 MGA is the fuel gauge. The car has been driven about once a year for the last 20 years for no more than 1000 miles until I acquired it a few months ago. The fuel gauge indicator does move sightly in the right direction when the key is turned on. I have put gas in the car so I know there is at least a half a tank. I figured that the float might be stuck after sitting so long in one place. Today I cleaned off the tank sending unit exterior and ran a wire from the post on the sending assy to a ground. My reasoning was that if I grounded the sending unit, the gauge would read full. It did not move past where it has been moving to. What would be my next step in trouble shooting the problem?
Thanks,
Charlie


Gliderman8

Yoda
Gold
Country flag
Offline
You might check to see if the float has gas in it. I had a similar problem with my TR6.... I knew there was gas in the tank but it read very low. The problem was that the plastic float had fuel in it. I replaced it with a brass float which fixed my problem.

OP
C

Coastalman

Jedi Warrior
Silver
Country flag
Offline
I did a test of the gauge by putting a ground lead to the side of the gauge going to the sending unit. My expectation was that the gauge would read full if I grounded the sending unit side. The gauge did not move after the slight forward move that it has been doing when I turn the switch on. Did I have a false expectation that the gauge should read full if grounded?
I'm not going to pull the sending unit until I have another one in hand because I know the gasket will break when I remove it. I'm just checking other parts out before I do that.


DrEntropy

Great Pumpkin
Gold
Country flag
Offline
If the sending unit is stopped in one position for a length of time, the rheostat can get "stuck" in position. Not uncommon with oddly mixed fuel (ethanol) Just had an old Rolls with that issue in Sarasota. Soaked the sending unit in CRC 2-26 for a day, finally got the arm to budge, then worked it GENTLY a bit at a time, got it to move through a complete arc and now it works again.

But the gauge should have gone full travel with the lead grounded. Try the same thing at the gauge itself.

OP
C

Coastalman

Jedi Warrior
Silver
Country flag
Offline
That's what I thought! I grounded the wire to the sending unit and, when that produced no result, I grounded the gauge on the down leg side. No movement on the gauge. Someone suggested putting a resistor in line when grounding, but my thoughts, just like you mentioned, was a straight ground would show maximum reading on the gauge. I am ordering a replacement sending unit and try that, but, right now, I don't feel like that is the problem. Most of my knowledgeable friends think it is. A step at a time.
Thanks,
Charlie


DrEntropy

Great Pumpkin
Gold
Country flag
Offline
Resistors are useless. Is it a Lucas or Jaeger? Look to Joe Curto or Nisonger for a gauge replacement.


JPSmit

Moderator
Staff member
Silver
Country flag
Offline
Resistors are useless. Is it a Lucas or Jaeger? Look to Joe Curto or Nisonger for a gauge replacement.



runs and hides - back to the conversation.


DrEntropy

Great Pumpkin
Gold
Country flag
Offline
:lol:
