Wiring Diagram for Fog Lights

[tahoe healey]

I need a wiring diagram for fog lights with 3 relays. Anyone have this?



[roscoe]

Just curious, not sure why you want 3 relays?.



[mezy]

front or rear fog lights, and like roscoe has asked why three relays when one will do



[tahoe healey]

One for each head lamp and one for the fog lights. I've had this set up for the last 15-18 years using a second 3 position switch replacing the dash light switch. Position1 = off, position 2 =dash lights, Position 3 = dash lights and fog lights.
Unfortunately, I had a power failure somewhere and tore everything apart before I realized it was a blown axillary, in line fuse. I am trying to restore the system. It was a neat setup with fog lights off with high beams on.
I lost the original notes (senior moment). Norman Nock walked me through it originally. Dave had no ideas on this system and suggested some alternatives, but I loved the previous set-up.



[gonzo]

TH, I believe you shared your three-relay headlight low high beam and driving /fog lights schematic on this form those many years ago. I followed it to set up my relays. However, I operate the driving lights on a separate toggle. I check my notes and post them.



[tahoe healey]

I DID have a diagram, but it disappeared. I got a great one from a friend that I am about to use. I have a working system now that I engineered without the relays. (I added a pilot light to light me know when the fogs are on.) I prefer the relays.



[NutmegCT]

Bringing back some past lighting posts and diagrams:

Daniel Stern Lighting Consultancy and Supply

Detailed technical information: Fix dim headlamps!

www.danielsternlighting.com

Adding Auxilary fog lights

I am in the process of adding a pair of Lucas fog lights to my BJ8. Why? Becasue the previous owner put a badge bar on the car and it's kind of naked. Anyway, I am replacing the panel light switch with a head light switch that will control the panel lights in the mid position and the fog...

www.britishcarforum.com

Might be helpful.

Tom M.



[tahoe healey]

This is a great diagram that John Turney (of this forum) sent me. It made more sense and the job is done.



[BigGreen]

Thanks.



[bob hughes]

I have a layout somewhere with 2 relays, spots and fogs (all fitted with LEDs ) and with warning lights, wired through the Dipswitch with an over ride on the fogs, so they can be used seperatly. Note to self - I must find it.


Bob



[tahoe healey]

I did include a small "pilot" light to indicate when the fogs are on that is not included in John's diagram. The switch and light are on the drop-down gauge holder photo I posted earlier on the amp/volt thread.



[John Turney]

I did include a small "pilot" light to indicate when the fogs are on that is not included in John's diagram. The switch and light are on the drop-down gauge holder photo I posted earlier on the amp/volt thread.

Thanks for testing the wiring, TH. Now I know it works.

Some toggle switches have a LED light in the tip of the handle that lights when the switch is on.



[Patrick67BJ8]

Thanks for testing the wiring, TH. Now I know it works.

Some toggle switches have a LED light in the tip of the handle that lights when the switch is on.

I am looking for a lighted Lucas style switch to match the ones on my BJ8.
