Spitfire Brake line

Share this page

FlyingCat

FlyingCat

Jedi Hopeful
Country flag
Offline
I'm trying to replace the left rear brake line on my 1980 Spitfire -- the line that wraps around the brake plate and screws into the wheel cylinder. For whatever reason, this doesn't seem to be a part carried by any of the usual suspects (Parts Geek, JEGS, Moss, Rimmer Brothers, and British Parts NW). I's not even available at Classic Tube. SpitBits sells it as part of a "kit," but it's quite pricey, and I only need that one tube. So I don't want to do that if possible. I talked with a guy on the East Coast at Team Triumph, and he's going to check, so I guess there's some hope there. Here are my questions: Does anybody know where I can get one of those? And if not, any suggestions? Thanks!



Attachments

  • IMG_2951.jpg
    64.3 KB · Views: 108
You can fab up your own if needed. Go to any auto parts store and get a section of brake line. If the male fittings on your existing line are still good, take the pipe to a decent repair shop and they should be able to put your fittings on the new line and flare the ends. The copper lines are easy to bend by hand and are easy to flare.

You can look for the many brake pipes on the AGS website:
https://agscompany.com/product-category/brake-fuel-transmission-lines/
They have the British lines in multiple materials and lengths... look for something close in length to what you measure on the car.

Some of these pipes are also available through Amazon. Once you identify the length and part numbers from the AGS website, search for them on Amazon using the format....
"AGS XXX3##" (You need to include "AGS" with a space in the part number... no wildcards, no dashes)
Where XXX identifies the line material, 3 designates 3/16" pipe diameter, and ## is replaced by the length in inches.
For example, AGS BLB308 is an 8" long, 3/16" diameter, steel brake line.


[h=1][/h]

Great ideas! I went to that site. I'm thinking that could work. I just gave it a once over, but it seems like I can buy any length of steel pipe the width and length I need, with the fittings I need. So if I can't find the actual one on Amazon, all I would need do is bend the one I get from AGS, which I could probably figure out with the Internet. Am I seeing that right?

Were it me, I would remove the questionable pipe and measure it inch by inch using either a cloth (dress maker's) measuring tape or a string. You can usually tolerate a slightly longer pipe by moving the bends a bit. Bends can be made by any number of methods ranging from hand work around round objects to manual tube benders as shown in the HF link below.

https://www.harborfreight.com/tubing-bender-3755.html

I got the pipe off. It's 16" long and 3/16 wide, with a male fitting into the wheel cylinder, and a female fitting on the other end. I've found several places that are willing to sell me a tube bender. I'll check out HF and see who's the cheapest. It's just a question of flaring out the ends. Thanks!

That was the best advice of all. They had the part I was wanting, and for less than I would've spent making it myself (including shipping). Thank you!
